ATH M52 Tyre Changer – Heavy-Duty Semi-Automatic Tyre Machine for Run-Flats & UHP Tyres (14"–26")
In stock
SKU
ATH M52-1
As low as
£2,195.00
£2,634.00
Finance from £11.51 +VAT per week*
- Rear swivel with pneumatic mounting head clamping including automatic vertical and horizontal rim removal
- Control via ergonomically arranged foot pedals
- Including pneumatically controlled auxiliary assembly arm ATH A34 for effortless and damage-free assembly of low profile, UHP and run-flat tyres
- Self-centering, pre-adjustable 4-jaw system with two double-acting aluminium clamping cylinders; outside clamping range up to 22", additionally adjustable by -2"
- Lateral extractor with double-acting aluminium cylinder and anti-jamming system
- Ideally suited for car tyres, with optional accessories also for motorcycle bikes
- "12 Months Standard Warranty 24 Months Parts Warranty (subject to service contract)"
Technical Data
| Clamping range (inner / outer) | 14 – 26" / 12 – 24" |
| Rim width | 4 – 13" |
| Max. wheel diameter | 1.050 mm |
| Compressed air connection | 10 bar |
| Bead breaking range | 83 – 350 mm |
| Bead breaker force | 2.500 kg |
| Mounting speeds | 6 and 12 U/min |
| Driving power | 0,75 kW |
| Power supply voltage | 3x 400V / C16A |
| Noise level | 70 dB(A) |
Why Choose This Product?
"The ATH M52 is designed to give garages a professional, efficient, and durable tyre-changing platform that handles a wide variety of wheel sizes and tyre types — from standard car tyres to low-pro, UHP, and run-flats. Its pneumatic mounting head and ergonomic foot-pedal controls make operations smoother and faster, reducing physical straining and saving technician time. With its powerful bead-breaker, strong clamping system, and optional assist arm, the M52 offers a safer, more controlled alternative to manual tyre-changing — reducing the risk of rim damage, improving turnaround times and enhancing overall workshop productivity. Whether you run a high-throughput tyre shop, an MOT bay, or a versatile service garage, the ATH M52 offers professional-grade performance in a package built to deliver reliability and longevity."
Products You May Also Consider
FAQs About ATH M52 Tyre Changer – Heavy-Duty Semi-Automatic Tyre Machine for Run-Flats & UHP Tyres (14"–26")
What types of wheels is the ATH M52 suitable for?
The M52 handles a wide range of wheels, including car, SUV, 4x4, and light-commercial vehicle tyres.
It supports 14″–26″ internal clamping and 12″–24″ external clamping, with rim widths up to 13″ and wheel diameters up to 1,050 mm.
Is the machine suitable for run-flat and ultra-high-performance tyres?
Yes — the M52 is designed for tougher tyre applications.
Its powerful 2,500 kg bead breaker, dual-speed turntable, and optional A34 assist arm make it ideal for run-flats, UHP tyres, and low-profile tyres where additional control is required.
What power supply does the ATH M52 require?
The M52 operates on a 400V three-phase power supply.
Workshops without three-phase will need appropriate electrical infrastructure or an upgrade.
It also requires a stable 10-bar air supply for pneumatic functions.
