What types of wheels can the ATH W62 LCD 3D balance?

The ATH W62 LCD 3D can balance standard passenger cars, alloy and performance wheels, SUVs and 4x4 wheels, light-commercial vehicle wheels, and with optional adapters, motorcycle or speciality wheels.

What is the benefit of 3D automatic measurement?

The 3D measurement system automatically reads wheel distance, rim diameter, and rim width, providing faster setup, higher accuracy, and precise weight placement compared to traditional 1D/2D balancers.

Is the ATH W62 LCD 3D suitable for high-volume workshops?

Yes. With a fast cycle time, robust construction, laser-assisted positioning, and fully automatic measurement system, the W62 LCD 3D is ideal for busy tyre shops and MOT centres requiring continuous daily use.

ATH W62 LCD 3D Wheel Balancer – Fully-Automatic 3D Wheel & Tyre Balancing Machine for Cars & SUVs

ATH Heinl W62 LCD 3D Fully Automatic Balancer

The ATH W62 LCD 3D Wheel Balancer is a premium, fully automatic wheel-balancing solution designed for modern garages, tyre shops, MOT centres, and busy automotive service bays. With state-of-the-art 3D measurement technology, a large, easy-to-read LCD display, and a robust build tailored for frequent heavy-duty use, the W62 is engineered to deliver fast, accurate and repeatable results — whether you’re balancing standard car wheels, alloy rims, SUVs, or light commercial vehicle wheels.

Automatic distance, rim diameter and rim width (3D function) measurement
Operation via ergonomically arranged front control panel, large shelf with numerous compartments
Digital and optical position display of the weights via 19" LCD monitor and duo laser (LPS)
Static / dynamic, ALU programs, ALU weight optimization and back spoke placement
Quick-release nut clamping with 40 mm shaft diameter, easy attachment of the weights via pedal-operated parking brake and measuring tool, integrated interior wheel lighting
Wheel protection with automatic start-stop function
Precise work thanks to the latest microprocessor control
Ideally suited for car wheels, with optional accessories also for motorcycle and light truck wheels
"12 Months Standard Warranty 24 Months Parts Warranty (subject to service contract)"

Technical Data

Center hole diameter (rim)	45 – 130 mm
Measurement tolerance	± 1 g
Measuring time	7 s
Measuring speed	180 U/min
Rim width	1.5 – 20"
Rim diameter	12 – 24"
Max. wheel diameter	900 mm
Wheel weight max.	65 kg
Driving power	0.25 kW
Power supply voltage	230V / C16A

Why Choose This Product?

"In today’s automotive market, wheel designs are becoming larger, wider, and more complex — with alloy rims, low-profile tyres, and performance wheels now common. The ATH W62 LCD 3D meets these challenges head-on with advanced automatic 3D measurement, precise laser-guided weight placement, and versatile balancing programs. For tyre shops, MOT centres, fast-fit bays, or performance-focused garages, this balancer helps you deliver consistent quality, reduce error-related comebacks and increase throughput — translating into better customer satisfaction and higher profitability. Whether you’re upgrading an existing bay or setting up a new one, the W62 offers superior precision, speed and reliability — making it a future-proof, professional-grade solution for wheel balancing."
